Set:
- engineHONDA GXV390
- pump typecentrifugal aluminum housing
- floatpolyethylene / polyurethane
- platealuminum alloy
- suction coveraluminum alloy
- impelleraluminum alloy
Application:
Pumps used by fire brigades to filling water tanks from natural reservoirs. In addition, pump can be used to pump water from flooded or flooded areas. Its application it is also found in forestry, including fighting forest and peat fires, etc.
design of pump, depending on pressure, sufficient amount of water 3 pressure fire hoses, tomchisle: 1 -77 mm in diameter and 2-diameter 51 mm.
Attention! pump cannot be used in enclosed spaces where there is danger of carbon monoxide poisoning!
BASIC SPECIFICATIONS:
| Settings | PH-CYKLON 2/1500 |
| Pump | |
| Maximum flow | 1540 l/min |
| Maximum discharge height | 55 |
| Maximum speed | 3500 rpm |
| Pressure port with | GM-80 |
| Honda Engine GXV 390 | |
| Maximum power | 7.6 kW / 3600 rpm |
| Volume of cylinder | 389 cm 3 |
| Weight | 32 kg |
| fuel Consumption | 2,9 l/h |
| Float | |
| Dimensions | 970x700x205 mm |
| Weight float | 10.3 kg |
| Complete pump | |
| curb Weight pump | 54 kg |
| Total weight | 56 kg |
| Dimensions | 1030x740x430 mm |
